2025 Generac Portable Generator, 15500
$0.00
No Job Too Tough. No Workday Too Long.
If you’ve got a tough job to do, look no further than the XD5000E generator.
The sturdy steel frame features an integrated lifting eye for easy transport and on-site security. 6% total harmonic distortion — for smooth operation of tools, appliances, even sensitive electronics. And it’s engineered to keep on running, thanks to its large fuel tank.
Specifications
- Product Series: GP15500EFI
- Model (Configuration): 7705-0 (Epa/49-State)
- Ac Rated Output Running Watts: 15500
- Ac Maximum Output Motor Starting Watts: 19300
- Rated Ac Voltage: 120/240 Vac
- Rated Ac Frequency: 60 Hz
- Rated Vac Amperage: 64.5/129
- Engine Displacement: 816Cc
- Engine Type: Ohvi
- Engine Rpm: 3600
- Recommended Oil: 10W-30 / Sae30
- Oil Capacity Qt (L): W/ Filter Change: 2.2 (2.1), W/O Filter Change: 2.0 (1.95)
- Lubrication Method: Oil Pump
- Automatic Voltage Regulation (Avr): Yes
- Starting Method: Electric
- Low Oil Shutdown Method: Low Pressure
- Battery Included: Yes
- Battery Type: Group U1
- Battery Part No.: N/A (Replacement batteries must be purchased locally)
- Battery Dimensions: Group U1 Has A Standard Case Size
- Neutral Bonded To Ground: Yes - Neutral Bonded To Frame
- Start Switch Type: Off/Run/Start Switch
- Switch Location: On Control Panel
- Fuel Gauge: Built-In Tank
- Fuel Tank Capacity Gal (L): 14.2 (54.0)
- Run Time At 50% Load (Hours): 11
- Handle Style: Folding, Locking
- Wheel Type: 12" Never-Flat Wheels
- Warranty- Residential: 3 Year Limited
- Warranty- Commercial: 2 Year Limited
Dimensions and Weight
- Length in (mm): 58.5 (1485)
- Width in (mm): 30.9 (785.5)
- Height in (mm): 36.5 (928.1)
- Carton Length in (mm): 40 (1016)
- Carton Width in (mm): 27 (685.8)
- Carton Height in (mm): 37.7 (958.2)
- Unit Weight Ibs (Kg): 420 (191)
- Shipping Weight Ibs (Kg): 450 (204)
Features
- Cosense® Technology: STOPS, ALERTS, SAVES. Powerful protection from hazardous carbon monoxide.
- Generac 816Cc Efl Engine: Delivers The Right Amount Of Power To Get The Best Performance And Efficiency Out Of Your Engine.
- True Power Technology: With Less Than <5% Thd To Safely Power Sensitive Electronic Equipment In Your Home.
- Low-Oil Pressure Shutdown: Automatically Safeguards Engine From Damage.
- Large-Capacity Fuel Tank: With Incorporated Fuel Gauge Provides Durability And Extended Run Times.
- Hardened 1 1/4" Steel Tube Cradle: For Added Strength And Durability.
- Hour Meter: tracks maintenance intervals.
- Heavy-Duty, Never-Flat Wheels: For Reliable Portability.
- Electric Start: Battery Included, Provides Hassle-Free Start-Up.
Additional information
| Engine | Engine Type OHVI Displacement 816cc |
|---|---|
| Dimensions | Length 58.5 in. (1485 mm) Width 30.9 in. (785.5 mm) Height 36.5 in. (928.1 mm) Weight Unit: 420 lb. (191 kg) ; Shipping: 450 lb. (204 kg) |
| Other | AC Output 15500 Fuel Tank Capacity 14.2 gal. (54.0 L) Run Time at 50% of Rated Load: 11 |
